LB-402VD Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance of the LB-402VD?
  ROHM recommends a 4-layer PCB with a solid ground plane and a separate power plane for the input and output stages. The input and output pins should be placed on the top layer, and the decoupling capacitors should be placed as close as possible to the device.
• How do I ensure the LB-402VD operates within its specified temperature range?
  The LB-402VD is rated for operation between -40°C to 125°C. Ensure proper heat dissipation by providing a sufficient heat sink, and avoid exposing the device to extreme temperatures during storage or operation.
• What is the recommended input capacitor value and type for the LB-402VD?
  ROHM recommends using a 10uF to 22uF ceramic capacitor (X5R or X7R type) with a voltage rating of 50V or higher, placed as close as possible to the VIN pin.
• Can I use the LB-402VD in a high-reliability or automotive application?
  Yes, the LB-402VD is AEC-Q100 qualified and suitable for high-reliability and automotive applications. However, ensure that the device is used within its specified operating conditions and follows the recommended PCB layout and thermal management guidelines.
• How do I troubleshoot issues with the LB-402VD, such as output voltage instability or overheating?
  Check the input voltage, output load, and PCB layout for any errors or inconsistencies. Verify that the device is operated within its specified temperature range and that the recommended decoupling capacitors are used. If issues persist, consult ROHM's application notes and technical support resources.
