LB-602MA2 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance of the LB-602MA2?
  ROHM recommends a 4-layer PCB with a solid ground plane and a separate power plane for the IC. The input and output pins should be placed on the top layer, and the decoupling capacitors should be placed as close as possible to the IC.
• How do I ensure the LB-602MA2 operates within its specified temperature range?
  The LB-602MA2 is rated for operation between -40°C to 85°C. Ensure good thermal design, including a heat sink if necessary, and avoid exposing the IC to extreme temperatures during storage or operation.
• What is the recommended input voltage range for the LB-602MA2?
  Although the datasheet specifies a minimum input voltage of 2.7V, ROHM recommends an input voltage range of 3.0V to 5.5V for optimal performance and to ensure the IC operates within its specified parameters.
• How do I handle the LB-602MA2's power-on reset (POR) circuitry?
  The LB-602MA2 has an internal POR circuit that resets the IC during power-up. Ensure that the input voltage rises slowly and monotonically to avoid false resets. A capacitor between the VCC pin and GND can help filter out noise and ensure a clean power-up sequence.
• What is the maximum allowable output current for the LB-602MA2?
  Although the datasheet specifies a maximum output current of 100mA, ROHM recommends limiting the output current to 50mA to ensure the IC operates within its specified temperature range and to prevent overheating.
