LB11923V - onsemi

LB11923V Details

• Manufacturer Part Number:

  LB11923V

• Part Life Cycle Code:

  Active

• Package Description:

  0.275 INCH, SSOP-44

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  onsemi

• YTEOL:

  7.5

• Analog IC - Other Type:

  3-PHASE BRUSHLESS DC MOTOR CONTROLLER

• JESD-30 Code:

  R-PDSO-G44

• Length:

  15 mm

• Number of Functions:

  1

• Number of Terminals:

  44

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  0.03 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LSSOP

• Package Equivalence Code:

  SSOP44,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, LOW PROFILE, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.7 mm

• Supply Current-Max (Isup):

  29500 mA

• Supply Voltage-Max (Vsup):

  7 V

• Supply Voltage-Min (Vsup):

  4.4 V

• Supply Voltage-Nom (Vsup):

  6.3 V

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  5.6 mm
