LB303MK - ROHM Semiconductor

Description: Display Modules - LED Character and Numeric Green 7-Segment 3 Character Common Cathode 2.1V 10mA 0.512" H x 0.866" W x 0.197" D (13.00mm x 22.00mm x 5.00mm) 12-DIP (0.362", 9.20mm)

Download LB303MK Model

Schematic
symbols

PCB
footprints

3D
models

Alert me if there are changes to this LB303MK model

Email notifications will be applied after download.

Send part feedback

Symbol

LB303MK - ROHM Semiconductor - PCB symbol

PCB Footprints

LB303MK - ROHM Semiconductor PCB footprint - Other - Other - 12-DIP_2025-2

3D Models

LB303MK - ROHM Semiconductor - 3D model - Other - 12-DIP_2025-2

Datasheet Download Datasheet
Stock & Prices Price & Stock for LB303MK
Part Number LB303MK
Manufacturer ROHM Semiconductor
Pin Count 11
Part Category Display
Package Category Other
Footprint Name Other - 12-DIP_2025-2
Released Date Apr 24, 2025
Last Modified Date Apr 24, 2025 2:23 PM UTC
Pinout / Pin List Click Here (Member Only)

LB303MK Details

Manufacturer Part Number:
LB303MK
Manufacturer:
ROHM Semiconductor

Trust Checks

Community Provided

System Verified

Community Approved

LB303MK Overview

Use the download button to access the LB303MK schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like LB303, or try a keyword search, such as LED Displays
