LC898300XA - onsemi

LC898300XA Details

• Manufacturer Part Number:

  LC898300XA

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  WLP-9

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  onsemi

• YTEOL:

  3

• Analog IC - Other Type:

  3-PHASE BRUSHLESS DC MOTOR CONTROLLER

• JESD-30 Code:

  R-PBGA-B9

• Length:

  1.39 mm

• Number of Functions:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Output Current-Max:

  0.15 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  UFBGA

• Package Equivalence Code:

  BGA9,3X3,16

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, ULTRA THIN PROFILE, FINE PITCH

• Seated Height-Max:

  0.56 mm

• Supply Voltage-Max (Vsup):

  3.3 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Supply Voltage-Nom (Vsup):

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Width:

  1.21 mm
