LCS702HG - Power Integrations

LCS702HG Details

• Manufacturer Part Number:

  LCS702HG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SIP

• Pin Count:

  16/13

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Power Integrations

• YTEOL:

  0

• High Side Driver:

  YES

• Interface IC Type:

  HALF BRIDGE BASED IGBT/MOSFET DRIVER

• JESD-30 Code:

  R-PZIP-T13

• Length:

  16.51 mm

• Number of Functions:

  1

• Number of Terminals:

  13

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SZIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE, SHRINK PITCH

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Supply Voltage-Max:

  15 V

• Supply Voltage-Min:

  11.4 V

• Supply Voltage-Nom:

  12 V

• Surface Mount:

  NO

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  0.97 mm

• Terminal Position:

  ZIG-ZAG

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  2.01 mm
