LGA50D-01DADJJ - Advanced Energy

LGA50D-01DADJJ Details

• Manufacturer Part Number:

  LGA50D-01DADJJ

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-28

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Advanced Energy Industries Inc

• YTEOL:

  5

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  EN, UKCA

• Efficiency (Main Output):

  95.5%

• Input Voltage-Max:

  14 V

• Input Voltage-Min:

  7.5 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-XQMA-X28

• Length:

  25.4 mm

• Line Regulation-Max:

  1%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  28

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  50 A

• Output Voltage-Max:

  5 V

• Output Voltage-Min:

  0.6 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  QMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE, OVER TEMPERATURE

• Ripple Voltage (Main Out):

  0.00707 Vrms

• Screening Level:

  EN 62368-1

• Seated Height-Max:

  12.2 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  QUAD

• Total Power Output-Max:

  120 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  5 s

• Width:

  12.7 mm
