LGN2H680MELA25 - Nichicon

LGN2H680MELA25 Details

• Manufacturer Part Number:

  LGN2H680MELA25

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00

• Manufacturer:

  Nichicon Corporation

• YTEOL:

  6

• Capacitance:

  68 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  25 mm

• Dielectric Material:

  ALUMINUM (WET)

• JESD-609 Code:

  e3

• Leakage Current:

  0.55 mA

• Length:

  25 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -25 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  Snap-in

• Packing Method:

  Bulk

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  500 V

• Ripple Current:

  520 mA

• Surface Mount:

  NO

• Tan Delta:

  0.2

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Pitch:

  10 mm

• Terminal Shape:

  SNAP-IN
