LGU2G560MELY - Nichicon

LGU2G560MELY Details

• Manufacturer Part Number:

  LGU2G560MELY

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CAN

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00

• Manufacturer:

  Nichicon Corporation

• YTEOL:

  6

• Capacitance:

  56 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  20 mm

• Dielectric Material:

  ALUMINUM (WET)

• JESD-609 Code:

  e2

• Leakage Current:

  0.44 mA

• Length:

  25 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -25 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  Snap-in

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  400 V

• Ripple Current:

  510 mA

• Surface Mount:

  NO

• Tan Delta:

  0.15

• Terminal Finish:

  Matte Tin/Copper (Sn/Cu)

• Terminal Pitch:

  10 mm

• Terminal Shape:

  SNAP-IN
