LM138KSTEEL/NOPB - Texas Instruments

LM138KSTEEL/NOPB Details

• Manufacturer Part Number:

  LM138KSTEEL/NOPB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Adjustability:

  ADJUSTABLE

• Dropout Voltage1-Nom:

  3 V

• Input Voltage-Max:

  40 V

• Input Voltage-Min:

  4.2 V

• Input-Output Voltage Differential-Max:

  40 V

• Input-Output Voltage Differential-Min:

  3 V

• JESD-30 Code:

  O-XBFM-P2

• Line Regulation-Max (%/V):

  0.04

• Load Regulation-Max(%):

  0.6%

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  2

• Operating Temperature TJ-Max:

  150 °C

• Operating Temperature TJ-Min:

  -55 °C

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Current1-Max:

  5 A

• Output Voltage1-Max:

  32 V

• Output Voltage1-Min:

  1.24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  BFM

• Package Equivalence Code:

  TO-204/-3

• Package Shape:

  ROUND

• Package Style:

  FLANGE MOUNT

• Packing Method:

  TRAY

• Qualification Status:

  Not Qualified

• Regulator Type:

  ADJUSTABLE POSITIVE SINGLE OUTPUT STANDARD REGULATOR

• Seated Height-Max:

  8.94 mm

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Form:

  PIN/PEG

• Terminal Position:

  BOTTOM

• Voltage Tolerance-Max:

  4%
