LM2576T-5.0LB03 - Texas Instruments

LM2576T-5.0LB03 Details

• Manufacturer Part Number:

  LM2576T-5.0LB03

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ZIP, ZIP5,.15,.2,67TB

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  VOLTAGE-MODE

• JESD-30 Code:

  R-PZIP-T5

• JESD-609 Code:

  e0

• Moisture Sensitivity Level:

  1

• Number of Terminals:

  5

• Output Current-Max:

  3 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP5,.15,.2,67TB

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Switching Frequency-Max:

  63 kHz

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.7 mm

• Terminal Position:

  ZIG-ZAG

• Time@Peak Reflow Temperature-Max (s):

  40
