The recommended input capacitor value is 10uF to 22uF, depending on the input voltage and output current requirements. A larger capacitor value can help to reduce input voltage ripple and improve output voltage regulation.
To ensure the LM2623MMX/NOPB operates within its SOA, ensure that the input voltage, output current, and ambient temperature are within the recommended operating conditions specified in the datasheet. Additionally, ensure that the device is properly heat-sinked and that the thermal resistance (RθJA) is within the recommended range.
The maximum output current that the LM2623MMX/NOPB can deliver is 3A. However, the actual output current may be limited by the input voltage, output voltage, and thermal considerations.
The LM2623MMX/NOPB is rated for operation up to 125°C. However, the device's performance and reliability may degrade at high temperatures. It is recommended to derate the output current and ensure proper heat-sinking to ensure reliable operation in high-temperature environments.
To minimize EMI, ensure that the PCB layout follows good electromagnetic compatibility (EMC) practices. Keep the input and output traces separate, use a solid ground plane, and minimize loop areas. Additionally, use shielding and filtering components as necessary to reduce EMI.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LM2623MMX/NOPB Overview
Use the download button to access the LM2623MMX/NOPB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM262,
or try a keyword search, such as Switching Regulator or Controllers
