Texas Instruments provides a recommended PCB layout in the datasheet, but it's also recommended to follow general high-frequency PCB design guidelines, such as keeping the input and output traces short and separate, using a solid ground plane, and minimizing loop areas.
To ensure stability, follow the datasheet's guidelines for component selection, such as choosing the correct output capacitor and resistor values. Additionally, make sure to decouple the input and output with capacitors, and consider adding a small series resistor to the output to dampen oscillations.
The LM3477MMX/NOPB has an operating junction temperature range of -40°C to 125°C, but the maximum ambient temperature range depends on the specific application and thermal design. A general rule of thumb is to derate the device by 1°C/W above 25°C ambient temperature.
The LM3477MMX/NOPB is a commercial-grade device, but Texas Instruments offers automotive-grade and high-reliability versions of the device, such as the LM3477QMMX/NOPB and LM3477SMX/NOPB, respectively. These devices have additional testing and qualification for high-reliability and automotive applications.
Start by checking the input voltage, output load, and component values against the datasheet's recommendations. Use an oscilloscope to measure the output voltage and current, and check for signs of oscillation or instability. Also, verify that the device is properly soldered and that there are no thermal issues or hotspots.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LM3477MMX/NOPB Overview
Use the download button to access the LM3477MMX/NOPB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM347,
or try a keyword search, such as Switching Regulator or Controllers
