LM3578AH - Texas Instruments

Description: • Inverting and Non-Inverting Feedback Inputs easily be set up for such DC-to-DC voltage • 1.0V Reference at Inputs conversion circuits as the buck, boost, and inverting • Operates from Supply Voltages of 2V to 40V configurations. • Output Current up to 750mA, Saturation Less than 0.9V • Current Limit and Thermal Shut Down • Duty Cycle up to 90%
