Texas Instruments provides a recommended PCB layout in the datasheet, but it's also recommended to follow general high-frequency PCB design guidelines, such as using a solid ground plane, minimizing trace lengths, and using vias to connect the input and output capacitors to the ground plane.
To ensure stability, follow the recommended component values and PCB layout, and make sure the input and output capacitors are properly selected and placed. Additionally, the datasheet provides a stability analysis section that can help you determine the stability of the device.
The maximum input voltage is not explicitly stated in the datasheet, but according to the absolute maximum ratings, the device can handle up to 42V. However, it's recommended to operate the device within the recommended operating conditions to ensure reliability and performance.
The LM5021MMX-2 is rated for operation up to 125°C, but the device's performance and reliability may degrade at high temperatures. It's recommended to follow the recommended operating conditions and consider derating the device's performance at high temperatures.
Texas Instruments provides a troubleshooting guide in the datasheet, which covers common issues such as output voltage regulation, input voltage range, and stability. Additionally, you can use oscilloscopes and other measurement tools to debug the circuit and identify the root cause of the issue.
