The LM5166YDRCT can handle input voltages up to 65V, but it's recommended to operate within the specified input voltage range of 4.5V to 60V for optimal performance.
To ensure stability, it's essential to follow the recommended layout and component selection guidelines, including the use of a suitable output capacitor and a low-ESR input capacitor. Additionally, the output voltage can be adjusted using the FB pin, and the output voltage stability can be improved by adding a capacitor in parallel with the output resistor.
The LM5166YDRCT can deliver up to 2A of output current, but the actual output current capability may be limited by the input voltage, output voltage, and thermal considerations.
The LM5166YDRCT has built-in overcurrent protection (OCP) and thermal shutdown (TSD) features. The OCP limit is typically set to 3.5A, and the TSD threshold is around 150°C. Additionally, it's recommended to add external protection components, such as fuses or PTC thermistors, to ensure safe operation.
The LM5166YDRCT is rated for operation up to 125°C, but the maximum junction temperature (TJ) should not exceed 150°C. It's essential to ensure proper thermal design and heat sinking to maintain a safe operating temperature.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LM5166YDRCT Overview
Use the download button to access the LM5166YDRCT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LM516,
or try a keyword search, such as Switching Regulator or Controllers
