LM555H/883 - Texas Instruments

LM555H/883 Details

• Manufacturer Part Number:

  LM555H/883

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  BCY

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Analog IC - Other Type:

  PULSE; RECTANGULAR

• JESD-30 Code:

  O-MBCY-W8

• Length:

  9.08 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Frequency-Max:

  0.051 MHz

• Package Body Material:

  METAL

• Package Code:

  TO-5

• Package Equivalence Code:

  CAN8,.2

• Package Shape:

  ROUND

• Package Style:

  CYLINDRICAL

• Qualification Status:

  Not Qualified

• Screening Level:

  MIL-STD-883

• Seated Height-Max:

  4.4 mm

• Supply Current-Max (Isup):

  18.5 mA

• Supply Voltage-Max (Vsup):

  15 V

• Supply Voltage-Min (Vsup):

  5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  MILITARY

• Terminal Form:

  WIRE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  BOTTOM

• Width:

  9.08 mm
