LM7805CK - Texas Instruments

LM7805CK Details

• Manufacturer Part Number:

  LM7805CK

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TO-204AA

• Package Description:

  METAL TO-3, CAN-2

• Pin Count:

  2

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Adjustability:

  FIXED

• Dropout Voltage1-Nom:

  2 V

• Input Voltage Absolute-Max:

  35 V

• Input Voltage-Max:

  20 V

• Input Voltage-Min:

  7.5 V

• JESD-30 Code:

  O-MBFM-P2

• Line Regulation-Max:

  0.05%

• Load Regulation-Max:

  0.05%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  2

• Operating Temperature TJ-Max:

  125 °C

• Output Current1-Max:

  1 A

• Output Voltage1-Max:

  5.25 V

• Output Voltage1-Min:

  4.75 V

• Output Voltage1-Nom:

  5 V

• Package Body Material:

  METAL

• Package Code:

  BFM

• Package Equivalence Code:

  TO-204/-3

• Package Shape:

  ROUND

• Package Style:

  FLANGE MOUNT

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Form:

  PIN/PEG

• Terminal Position:

  BOTTOM

• Voltage Tolerance-Max:

  5%
