Texas Instruments provides a recommended PCB layout in the application note SLUA477, which includes guidelines for thermal vias, copper pours, and component placement to ensure optimal thermal performance.
The LM95235EIMM/NOPB has a built-in calibration mechanism. Refer to the calibration procedure outlined in the datasheet, which involves writing specific values to the calibration registers to achieve high accuracy.
The maximum cable length for the I2C interface depends on the system design and noise environment. As a general guideline, Texas Instruments recommends keeping the cable length below 10 inches (25 cm) to ensure reliable communication. For longer cable lengths, consider using I2C bus repeaters or buffers.
Yes, the LM95235EIMM/NOPB is designed to support hot-swap applications. The device has built-in power-on reset and brown-out detection, which ensures that the device resets properly during hot-swap events. However, additional external circuitry may be required to ensure safe hot-swap operation.
The LM95235EIMM/NOPB has a built-in thermal shutdown feature that activates when the device temperature exceeds a certain threshold. During thermal shutdown, the device outputs are disabled, and the device enters a low-power state. To handle thermal shutdown, design a system that can detect and respond to the thermal shutdown event, such as by generating an interrupt or resetting the system.
