LMG3626ZREQR - Texas Instruments

LMG3626ZREQR Details

• Manufacturer Part Number:

  LMG3626ZREQR

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Case Connection:

  SOURCE

• Configuration:

  SINGLE WITH BUILT-IN GATE DRIVER

• DS Breakdown Voltage-Min:

  700 V

• Drain Current-Max (ID):

  3.2 A

• Drain-source On Resistance-Max:

  0.308 Ω

• FET Technology:

  JUNCTION

• JESD-30 Code:

  R-PQCC-N38

• Number of Elements:

  1

• Number of Terminals:

  38

• Operating Mode:

  DEPLETION MODE

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Polarity/Channel Type:

  N-CHANNEL

• Pulsed Drain Current-Max (IDM):

  10.7 A

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Position:

  QUAD

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  GALLIUM NITRIDE
