LMG3650R025KLAR - Texas Instruments

LMG3650R025KLAR Details

• Manufacturer Part Number:

  LMG3650R025KLAR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN GATE DRIVER

• DS Breakdown Voltage-Min:

  650 V

• Drain Current-Max (ID):

  50 A

• Drain-source On Resistance-Max:

  0.03 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  R-PSSO-F8

• Moisture Sensitivity Level:

  3

• Number of Elements:

  1

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Pulsed Drain Current-Max (IDM):

  85 A

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  FLAT

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  GALLIUM NITRIDE

• Turn-off Time-Max (toff):

  60 ns

• Turn-on Time-Max (ton):

  55 ns
