Texas Instruments provides a recommended PCB layout in the datasheet, but it's also recommended to follow general high-frequency PCB design guidelines, such as using a solid ground plane, minimizing trace lengths, and using 50-ohm transmission lines for the input and output signals.
The LMH2191 requires a specific bias voltage and current to operate optimally. Ensure that the VCC pin is connected to a stable 5V power supply, and the ISET pin is connected to a resistor that sets the desired output current. Refer to the datasheet for specific biasing requirements.
The LMH2191 can handle input signal amplitudes up to 2Vpp differential, but it's recommended to limit the input signal amplitude to 1.5Vpp differential to ensure optimal performance and prevent distortion.
The LMH2191 has a built-in low-pass filter, but additional filtering may be required to remove high-frequency noise and unwanted signals. Consider adding external filters, such as a low-pass filter or a band-pass filter, to the output of the LMH2191 to achieve the desired signal quality.
The LMH2191 has a maximum junction temperature of 150°C. Ensure good thermal management by providing adequate heat sinking, such as a thermal pad or a heat sink, and keeping the device away from heat sources. Refer to the datasheet for thermal resistance and power dissipation information.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LMH2191TMX/NOPB Overview
Use the download button to access the LMH2191TMX/NOPB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LMH21,
or try a keyword search, such as Clock Drivers
