Texas Instruments recommends a 4-layer PCB with a solid ground plane, and to keep the input and output traces as short as possible. Additionally, it's recommended to use a common mode choke or a ferrite bead to filter out high-frequency noise.
To ensure stability, make sure to follow the recommended component values and PCB layout. Additionally, ensure that the input and output capacitors are of high quality and have low ESR. It's also recommended to add a small resistor (e.g. 10 ohms) in series with the output capacitor to dampen any oscillations.
The maximum power dissipation of the LMH6502MT/NOPB is dependent on the ambient temperature and the thermal resistance of the PCB. However, as a general rule, the maximum power dissipation is around 1.5W. It's recommended to use a heat sink or to ensure good airflow to keep the device within its operating temperature range.
The LMH6502MT/NOPB is rated for operation up to 125°C. However, the device's performance and reliability may degrade at high temperatures. It's recommended to derate the device's power dissipation and to ensure good airflow or heat sinking to keep the device within its operating temperature range.
To troubleshoot issues with the LMH6502MT/NOPB, start by checking the input and output voltages, and ensure that the device is properly biased. Use an oscilloscope to check for oscillations or noise on the output. Also, check the PCB layout and ensure that it follows the recommended layout guidelines. If the issue persists, consult the datasheet and application notes for further guidance.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LMH6502MT/NOPB Overview
Use the download button to access the LMH6502MT/NOPB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LMH65,
or try a keyword search, such as Other Signal Circuits
