LPC55S28JBD64K - NXP

Description: MCU 32-bit ARM Cortex M33 RISC 512KB Flash 3.3V 64-Pin HTQFP EP Tray

Download LPC55S28JBD64K Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LPC55S28JBD64K - NXP - PCB symbol
click to zoom
PCB Footprints
LPC55S28JBD64K - NXP PCB footprint - Quad Flat Packages - Quad Flat Packages - SOT855-5
click to zoom
3D Models
LPC55S28JBD64K - NXP - 3D model - Quad Flat Packages - SOT855-5
click to zoom

LPC55S28JBD64K Details

  • Manufacturer Part Number:

    LPC55S28JBD64K

  • Part Life Cycle Code:

    Active

  • HTS Code:

    8542.31.00.30

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    11

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Time@Peak Reflow Temperature-Max (s):

    30

  • uPs/uCs/Peripheral ICs Type:

    MICROCONTROLLER, RISC

Trust Checks

This model has been verified by system checks.
System Verified
Sponsored

LPC55S28JBD64K Overview

Use the download button to access the LPC55S28JBD64K schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LPC55, or try a keyword search, such as Microcontrollers
