LPC55S66JBD64E - NXP PCB footprint - Quad Flat Packages - Quad Flat Packages - SOT855-5
click to zoom
3D Models
LPC55S66JBD64E - NXP - 3D model - Quad Flat Packages - SOT855-5
click to zoom

LPC55S66JBD64E Details

  • Manufacturer Part Number:

    LPC55S66JBD64E

  • Part Life Cycle Code:

    Active

  • HTS Code:

    8542.31.00.30

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    8

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Tin (Sn)

  • Time@Peak Reflow Temperature-Max (s):

    30

  • uPs/uCs/Peripheral ICs Type:

    MICROCONTROLLER, RISC

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

LPC55S66JBD64E Overview

Use the download button to access the LPC55S66JBD64E schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LPC55, or try a keyword search, such as Microcontrollers
