LS05-26B12SS - Mornsun Power

LS05-26B12SS Details

• Manufacturer Part Number:

  LS05-26B12SS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMA, MODULE,6/16LEAD(UNSPEC)

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• Manufacturer:

  MORNSUN

• YTEOL:

  7

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, EN, IEC, UL

• Efficiency (Main Output):

  76%

• Input Voltage-Max:

  528 V

• Input Voltage-Min:

  90 V

• Input Voltage-Nom:

  115 V

• JESD-30 Code:

  R-XSMA-T6

• Length:

  44.5 mm

• Line Regulation-Max:

  1.5%

• Load Regulation-Max:

  2.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.42 A

• Output Voltage-Max:

  12.6 V

• Output Voltage-Min:

  11.4 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  SMA

• Package Equivalence Code:

  MODULE,6/16LEAD(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.06363 Vrms

• Screening Level:

  EN/IEC/UL 62368-1

• Seated Height-Max:

  24 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Total Power Output-Max:

  5 W

• Trim/Adjustable Output:

  NO

• Width:

  13 mm
