LT3032MPDE#PBF - Analog Devices

Description: LDO Voltage Regulators 2x 150mA Pos/Neg L N L Drop Lin Reg

Download LT3032MPDE#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LT3032MPDE#PBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LT3032MPDE#PBF - Analog Devices PCB footprint - Other - Other - DE14MA Package 14-Lead Plastic DFN (4mm × 3mm) LTC DWG # 05-08-1731 Rev C-ren1
click to zoom
3D Models
LT3032MPDE#PBF - Analog Devices - 3D model - Other - DE14MA Package 14-Lead Plastic DFN (4mm × 3mm) LTC DWG # 05-08-1731 Rev C-ren1
click to zoom

LT3032MPDE#PBF Details

  • Manufacturer Part Number:

    LT3032MPDE#PBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    DFN-14

  • Pin Count:

    14

  • Manufacturer Package Code:

    05-08-1731

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    8.5

  • JESD-30 Code:

    R-PDSO-N14

  • JESD-609 Code:

    e3

  • Length:

    4 mm

  • Line Regulation-Max:

    0.006%

  • Load Regulation-Max:

    0.015%

  • Load Regulation-Max(%):

    -0.075%

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Outputs:

    2

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Equivalence Code:

    SOLCC14,.12,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Regulator Type:

    ADJUSTABLE POSITIVE MULTIPLE OUTPUT LDO REGULATOR

  • Seated Height-Max:

    0.8 mm

  • Surface Mount:

    YES

  • Technology:

    BIPOLAR

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3 mm

LT3032MPDE#PBF Frequently Asked Questions (FAQs)

  • The maximum input voltage that can be applied to the LT3032MPDE is 15V, but it's recommended to operate within the specified input voltage range of 2.3V to 15V for optimal performance.
  • To ensure stability in the LT3032MPDE output, it's essential to follow the recommended layout and component selection guidelines, including the use of a minimum 10uF output capacitor and a 1uF input capacitor, and to avoid exceeding the maximum output current.
  • The recommended PCB layout for the LT3032MPDE involves placing the input and output capacitors close to the device, using a solid ground plane, and minimizing the length of the input and output traces to reduce noise and ensure stability.
  • The LT3032MPDE is rated for operation from -40°C to 125°C, but it's essential to consider the device's thermal characteristics and ensure proper heat sinking and cooling to prevent overheating and ensure reliable operation.
  • To troubleshoot issues with the LT3032MPDE output, start by verifying the input voltage and current, checking the output voltage and current, and ensuring that the device is properly configured and laid out according to the datasheet recommendations.
