LT8336EV#TRPBF - Analog Devices

Description: 40V, 2.5A, Low IQ Synchronous Step-Up Silent Switcher with PassThru

Download LT8336EV#TRPBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LT8336EV#TRPBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LT8336EV#TRPBF - Analog Devices PCB footprint - Other - Other - LQFN PACKAGE 16-LEAD (3mm × 3mm) LQFN_2024-11
click to zoom
3D Models
LT8336EV#TRPBF - Analog Devices - 3D model - Other - LQFN PACKAGE 16-LEAD (3mm × 3mm) LQFN_2024-11
click to zoom

LT8336EV#TRPBF Details

  • Manufacturer Part Number:

    LT8336EV#TRPBF

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Analog IC - Other Type:

    SWITCHING REGULATOR

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

LT8336EV#TRPBF Overview

Use the download button to access the LT8336EV#TRPBF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LT833, or try a keyword search, such as Switching Regulator or Controllers

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
