LTC1798CS8-5#TR - Analog Devices

LTC1798CS8-5#TR Details

• Manufacturer Part Number:

  LTC1798CS8-5#TR

• Part Life Cycle Code:

  Obsolete

• Package Description:

  0.150 INCH, LEAD FREE, PLASTIC, SOP-8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Analog IC - Other Type:

  THREE TERMINAL VOLTAGE REFERENCE

• JESD-30 Code:

  R-PDSO-G8

• JESD-609 Code:

  e0

• Length:

  4.9 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  70 °C

• Output Voltage-Max:

  5.0075 V

• Output Voltage-Min:

  4.9925 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.75 mm

• Supply Voltage-Max (Vsup):

  12.6 V

• Supply Voltage-Min (Vsup):

  5.2 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temp Coef of Voltage-Max:

  40 ppm/°C

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Trim/Adjustable Output:

  NO

• Width:

  3.9 mm
