A good layout and routing practice is to keep the analog and digital grounds separate, use a solid ground plane, and keep the analog and digital signals separate. Additionally, use a low-ESR capacitor for the VCC pin and a 0.1uF capacitor for the REFIN pin.
To ensure accuracy, use a high-quality external reference voltage, ensure the input signal is within the specified range, and use the correct gain and offset calibration. Additionally, consider using a low-noise, low-temperature-coefficient voltage reference.
The recommended power-up sequence is to apply VCC first, followed by the reference voltage (REFIN), and then the analog input signals. This ensures that the internal bias circuits are properly initialized.
The LTC2355IMSE-14#PBF has a maximum junction temperature of 150°C. To ensure reliable operation, ensure good airflow, use a heat sink if necessary, and avoid operating the device near its maximum temperature rating.
Use a low-impedance source, such as an op-amp buffer, to drive the analog input signals. This ensures that the input signals are not distorted or attenuated, and that the ADC can accurately convert the input signals.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LTC2355IMSE-14#PBF Overview
Use the download button to access the LTC2355IMSE-14#PBF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LTC23,
or try a keyword search, such as Analog to Digital Converters
