LTC2389CLX-16#PBF - Analog Devices

Description: LINEAR TECHNOLOGY - LTC2389CLX-16#PBF - Analogue to Digital Converter, 16 bit, 2.5 MSPS, Pseudo Differential, Single Ended

Download LTC2389CLX-16#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
LTC2389CLX-16#PBF - Analog Devices PCB footprint - Quad Flat Packages - Quad Flat Packages - 48-Lead 7mm × 7mm Plastic LQFP
click to zoom
3D Models
LTC2389CLX-16#PBF - Analog Devices  - 3D model - Quad Flat Packages - 48-Lead 7mm × 7mm Plastic LQFP
click to zoom

LTC2389CLX-16#PBF Details

  • Manufacturer Part Number:

    LTC2389CLX-16#PBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Pin Count:

    48

  • Manufacturer Package Code:

    05-08-1760

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Analog Input Voltage-Max:

    4.116 V

  • Analog Input Voltage-Min:

    -4.076 V

  • Conversion Time-Max:

    0.31 µs

  • Converter Type:

    ADC, SUCCESSIVE APPROXIMATION

  • JESD-30 Code:

    S-PQCC-N48

  • JESD-609 Code:

    e3

  • Length:

    7 mm

  • Linearity Error-Max (EL):

    0.0015%

  • Moisture Sensitivity Level:

    3

  • Number of Analog In Channels:

    1

  • Number of Bits:

    16

  • Number of Functions:

    1

  • Number of Terminals:

    48

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Bit Code:

    BINARY, OFFSET BINARY, 2S COMPLEMENT BINARY

  • Output Format:

    SERIAL, PARALLEL, WORD

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVQCCN

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Sample Rate:

    2.5 MHz

  • Sample and Hold / Track and Hold:

    SAMPLE

  • Seated Height-Max:

    0.8 mm

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    7 mm

LTC2389CLX-16#PBF Frequently Asked Questions (FAQs)

  • The recommended layout and routing for the LTC2389CLX-16#PBF involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the analog input traces. Additionally, it is recommended to use a low-ESR capacitor for the VCC pin and to keep the clock input traces short and away from the analog input traces.
  • To optimize the performance of the LTC2389CLX-16#PBF in high-frequency applications, it is recommended to use a low-jitter clock source, minimize the capacitive load on the output pins, and use a high-frequency-compatible layout and routing. Additionally, the use of a low-ESR capacitor for the VCC pin and a ferrite bead or RC filter on the VCC pin can help to reduce noise and improve performance.
  • The maximum operating temperature range for the LTC2389CLX-16#PBF is -40°C to 125°C. However, it is recommended to operate the device within a temperature range of -20°C to 85°C for optimal performance and reliability.
  • The digital output data from the LTC2389CLX-16#PBF is in a 16-bit parallel format. It is recommended to use a FIFO or a buffer to handle the output data, and to use a clock domain crossing circuit to synchronize the data with the system clock. Additionally, it is recommended to use a data alignment circuit to align the data with the system data bus.
  • The power consumption of the LTC2389CLX-16#PBF depends on the operating frequency and the supply voltage. At a supply voltage of 3.3V and an operating frequency of 100MSps, the typical power consumption is around 350mW. However, the power consumption can be reduced by using a lower supply voltage or by operating the device at a lower frequency.
