LTC2644IMS-L10#PBF - Analog Devices

Description: LINEAR TECHNOLOGY - LTC2644IMS-L10#PBF - Digital to Analogue Converter, 10 bit, 25 kSPS, 2.7V to 5.5V, MSOP, 12 Pins

Download LTC2644IMS-L10#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC2644IMS-L10#PBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC2644IMS-L10#PBF - Analog Devices PCB footprint - Small Outline Packages - Small Outline Packages - MS Package 12-Lead Plastic MSOP
click to zoom
3D Models
LTC2644IMS-L10#PBF - Analog Devices - 3D model - Small Outline Packages - MS Package 12-Lead Plastic MSOP
click to zoom

LTC2644IMS-L10#PBF Details

  • Manufacturer Part Number:

    LTC2644IMS-L10#PBF

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    MSOP-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Analog Output Voltage-Max:

    2.5 V

  • Converter Type:

    D/A CONVERTER

  • Input Bit Code:

    BINARY

  • JESD-30 Code:

    R-PDSO-G12

  • Length:

    4.9 mm

  • Linearity Error-Max (EL):

    0.097656%

  • Number of Bits:

    10

  • Number of Functions:

    1

  • Number of Terminals:

    12

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Equivalence Code:

    TSSOP12,.19

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Seated Height-Max:

    1.1 mm

  • Settling Time-Nom (tstl):

    7.4 µs

  • Supply Current-Max:

    6 mA

  • Supply Voltage-Nom:

    3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    3 mm

LTC2644IMS-L10#PBF Frequently Asked Questions (FAQs)

  • The recommended layout and placement for the LTC2644IMS-L10#PBF involves keeping the device away from high-frequency noise sources, using a solid ground plane, and placing decoupling capacitors close to the device. Additionally, it's recommended to use a 4-layer PCB with a dedicated power plane and a separate analog ground plane.
  • The LTC2644IMS-L10#PBF requires a single 2.7V to 5.5V power supply. It's recommended to use a low-noise, low-dropout regulator to power the device. Power sequencing is not critical, but it's recommended to power the device after the analog supply is stable.
  • The maximum clock frequency for the LTC2644IMS-L10#PBF is 50MHz. The device requires a clock signal with a minimum high time of 10ns and a minimum low time of 10ns. The clock signal should also have a maximum rise and fall time of 5ns.
  • The LTC2644IMS-L10#PBF can be configured for different output voltage ranges by adjusting the external resistors and capacitors. The device can output voltages from 0.5V to 5.5V, but the output voltage range is limited by the internal reference voltage and the external resistors.
  • The LTC2644IMS-L10#PBF has a maximum junction temperature of 150°C. Thermal management strategies include using a heat sink, reducing power consumption, and ensuring good airflow. The device is also available in a thermally-enhanced package option.
