LTC3569IUDTRPBF - Analog Devices

Description: Triple Buck Regulator with 1.2A and Two 600mA Outputs and Individual Programmable References

Download LTC3569IUDTRPBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC3569IUDTRPBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC3569IUDTRPBF - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - UD Package 20-Lead Plastic QFN (3mm × 3mm)
click to zoom
3D Models
LTC3569IUDTRPBF - Analog Devices - 3D model - Quad Flat No-Lead - UD Package 20-Lead Plastic QFN (3mm × 3mm)
click to zoom
  • Datasheet
  • Stock & Prices $ Price & Stock for LTC3569IUDTRPBF
  • Part Number LTC3569IUDTRPBF
  • Manufacturer Analog Devices
  • Pin Count 21
  • Part Category Integrated Circuit
  • Package Category Quad Flat No-Lead
  • Footprint Name Quad Flat No-Lead - UD Package 20-Lead Plastic QFN (3mm × 3mm)
  • Released Date Jan 11, 2017
  • Last Modified Date Nov 15, 2024 1:35 PM UTC
  • Pinout / Pin List Click Here (Member Only)
