LTC4126EV-ADJ#TRPBF - Analog Devices

Description: Wireless Li-Ion Charger with 1.2V Step-Down DC/DC Converter

Download LTC4126EV-ADJ#TRPBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC4126EV-ADJ#TRPBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC4126EV-ADJ#TRPBF - Analog Devices PCB footprint - Other - Other - LQFN Package 12-Lead (2mm × 2mm × 0.74mm) _2025-2
click to zoom
3D Models
LTC4126EV-ADJ#TRPBF - Analog Devices - 3D model - Other - LQFN Package 12-Lead (2mm × 2mm × 0.74mm) _2025-2
click to zoom

LTC4126EV-ADJ#TRPBF Details

  • Manufacturer Part Number:

    LTC4126EV-ADJ#TRPBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Pin Count:

    12

  • Manufacturer Package Code:

    05-08-1530

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Date Of Intro:

    2020-09-25

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    8.5

  • Analog IC - Other Type:

    LINEAR BATTERY CHARGER

  • Moisture Sensitivity Level:

    3

LTC4126EV-ADJ#TRPBF Frequently Asked Questions (FAQs)

  • The maximum input voltage that can be applied to the LTC4126EV-ADJ is 32V, but it's recommended to keep it below 28V for reliable operation.
  • The output voltage of the LTC4126EV-ADJ can be adjusted by connecting a resistor divider network between the VOUT pin and the ADJ pin. The ratio of the resistors determines the output voltage.
  • The minimum input voltage required for the LTC4126EV-ADJ to operate is 6.5V, but it's recommended to keep it above 7V for reliable operation.
  • The LTC4126EV-ADJ is rated for operation up to 125°C, but it's recommended to derate the output current and input voltage at high temperatures to ensure reliable operation.
  • The LTC4126EV-ADJ has built-in overcurrent protection and thermal shutdown. However, it's recommended to add external protection such as fuses and thermal sensors to ensure reliable operation.
