LTC6373SDFM#TRPBF - Analog Devices

LTC6373SDFM#TRPBF Details

• Manufacturer Part Number:

  LTC6373SDFM#TRPBF

• Brand Name:

  Analog Devices Inc

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  LFCSP:LEADFRM CHIP SCALE

• Package Description:

  DFN-12

• Pin Count:

  12

• Manufacturer Package Code:

  LFCSP:LEADFRM CHIP SCALE

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Date Of Intro:

  2020-08-18

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• Amplifier Type:

  INSTRUMENTATION AMPLIFIER

• Average Bias Current-Max (IIB):

  0.00005 µA

• Bandwidth (3dB)-Nom:

  6.5 MHz

• Common-mode Reject Ratio-Min:

  75 dB

• Input Offset Current-Max (IIO):

  0.00004 µA

• Input Offset Voltage-Max:

  1190 µV

• JESD-30 Code:

  S-PDSO-N12

• Length:

  4 mm

• Moisture Sensitivity Level:

  1

• Neg Supply Voltage Limit-Max:

  -20 V

• Neg Supply Voltage-Nom (Vsup):

  -15 V

• Non-linearity-Max:

  0.001%

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC12,.16,20

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR

• Seated Height-Max:

  0.8 mm

• Slew Rate-Nom:

  12 V/us

• Supply Current-Max:

  5.25 mA

• Supply Voltage Limit-Max:

  20 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Voltage Gain-Max:

  16

• Voltage Gain-Min:

  0.25

• Width:

  4 mm
