LTC6419HV#PBF - Analog Devices

Description: Operational Amplifier, 2 Channels, 10 GHz, 3300 V/µs, 2.7V to 5.25V, LQFN-EP, 20 Pins , -40℃~+125℃

Download LTC6419HV#PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
LTC6419HV#PBF - Analog Devices - PCB symbol
click to zoom
PCB Footprints
LTC6419HV#PBF - Analog Devices PCB footprint - Other - Other - LQFN Package 20-Lead (4mm × 3mm × 0.75mm)
click to zoom
3D Models
LTC6419HV#PBF - Analog Devices - 3D model - Other - LQFN Package 20-Lead (4mm × 3mm × 0.75mm)
click to zoom

LTC6419HV#PBF Details

  • Manufacturer Part Number:

    LTC6419HV#PBF

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Pin Count:

    20

  • Manufacturer Package Code:

    05-08-1519

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    8.5

  • Amplifier Type:

    OPERATIONAL AMPLIFIER

  • Architecture:

    VOLTAGE-FEEDBACK

  • Bandwidth (3dB)-Nom:

    1400 MHz

  • Common-mode Reject Ratio-Min:

    75 dB

  • Common-mode Reject Ratio-Nom:

    90 dB

  • Frequency Compensation:

    YES

  • Input Offset Current-Max (IIO):

    10 µA

  • Input Offset Voltage-Max:

    1400 µV

  • JESD-30 Code:

    R-XQCC-N20

  • Length:

    4 mm

  • Low-Offset:

    NO

  • Micropower:

    NO

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC20,.12X.16,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Packing Method:

    TRAY

  • Power:

    NO

  • Programmable Power:

    NO

  • Seated Height-Max:

    0.8 mm

  • Slew Rate-Nom:

    1580 V/us

  • Supply Current-Max:

    116 mA

  • Supply Voltage Limit-Max:

    5.5 V

  • Supply Voltage-Nom (Vsup):

    3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Unity Gain BW-Nom:

    10000000

  • Wideband:

    YES

  • Width:

    3 mm

LTC6419HV#PBF Frequently Asked Questions (FAQs)

  • A good PCB layout for the LTC6419HV involves keeping the input and output traces short and away from each other, using a solid ground plane, and placing the bypass capacitors close to the device. A 4-layer PCB with a dedicated ground plane is recommended. Additionally, the datasheet provides a recommended PCB layout and land pattern that should be followed.
  • The LTC6419HV requires a dual supply voltage (VCC and VEE) to operate. Ensure that the voltage supplies are well-regulated and decoupled with capacitors. The recommended bias voltage for VCC is 5V and for VEE is -5V. The datasheet provides a detailed description of the recommended biasing scheme.
  • The maximum input signal amplitude that the LTC6419HV can handle is ±10V. Exceeding this limit can cause the device to saturate or even damage it. It's essential to ensure that the input signal is within the specified range to maintain the device's linearity and accuracy.
  • To reduce noise and distortion in the output signal, ensure that the input signal is properly filtered and that the device is operated within its specified frequency range. Additionally, using a low-pass filter at the output can help to reduce high-frequency noise. The datasheet provides guidance on noise reduction techniques and output filtering.
  • The typical settling time of the LTC6419HV is around 100ns to 1μs, depending on the input signal frequency and amplitude. This settling time can be affected by the device's bandwidth, slew rate, and output load. The datasheet provides more information on the device's settling time and how it can be optimized.
