A 2-layer or 4-layer PCB with a solid ground plane and thermal vias is recommended. Ensure a minimum of 1 oz copper thickness and a thermal relief pattern around the device.
Implement a robust thermal management system, including a heat sink, thermal interface material, and a cooling fan if necessary. Monitor the device's junction temperature and adjust the system design accordingly.
Use low-ESR capacitors with a minimum capacitance of 10uF for the input and 22uF for the output. Ensure the capacitors are rated for the maximum operating voltage and have a low equivalent series resistance (ESR).
Use a shielded enclosure, keep the device and its components away from the PCB edge, and implement a multi-layer PCB with a solid ground plane. Ensure proper filtering and decoupling of the input and output lines.
Apply the input voltage first, followed by the enable signal. Ensure the input voltage is stable before applying the enable signal. A soft-start circuit can be implemented to reduce inrush current.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LV58063MC-AH Overview
Use the download button to access the LV58063MC-AH schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like LV580,
or try a keyword search, such as Switching Regulator or Controllers
