M10578-A3 - Antenova

Description: GPS Modules MediaTek MT3333 Flash Chip

Download M10578-A3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
M10578-A3 - Antenova PCB footprint - Other - Other - M10578-A3-1
click to zoom
3D Models
M10578-A3 - Antenova  - 3D model - Other - M10578-A3-1
click to zoom

M10578-A3 Details

  • Manufacturer Part Number:

    M10578-A3

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Contact Manufacturer

  • Package Description:

    MODULE-16

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Antenova M2M

  • Data Rate:

    115 Mbps

  • JESD-30 Code:

    S-XQMA-N16

  • Length:

    9 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    QMA

  • Package Shape:

    SQUARE

  • Package Style:

    MICROELECTRONIC ASSEMBLY

  • Seated Height-Max:

    2 mm

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:

    YES

  • Telecom IC Type:

    GNSS Module

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    1.85 mm

  • Terminal Position:

    QUAD

  • Width:

    9 mm
