M24LR64-RMN6/2 - STMicroelectronics

M24LR64-RMN6/2 Details

• Manufacturer Part Number:

  M24LR64-RMN6/2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Data Retention Time-Min:

  40

• Endurance:

  100000 Write/Erase Cycles

• I2C Control Byte:

  1010CDDR

• JESD-30 Code:

  R-PDSO-G8

• Memory Density:

  65536 bit

• Memory IC Type:

  EEPROM

• Memory Width:

  8

• Number of Terminals:

  8

• Number of Words:

  8192 words

• Number of Words Code:

  8000

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  8KX8

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP8,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Parallel/Serial:

  SERIAL

• Qualification Status:

  Not Qualified

• Serial Bus Type:

  I2C

• Standby Current-Max:

  0.00003 A

• Supply Current-Max:

  0.0007 mA

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Write Protection:

  SOFTWARE
