MA6Z121 - Panasonic

MA6Z121 Details

• Manufacturer Part Number:

  MA6Z121

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SC-88

• Package Description:

  SC-88, 6 PIN

• Pin Count:

  6

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.70

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  0

• Application:

  GENERAL PURPOSE

• Configuration:

  SEPARATE, 3 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• JESD-30 Code:

  R-PDSO-F6

• Number of Elements:

  3

• Number of Terminals:

  6

• Output Current-Max:

  0.1 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Reverse Recovery Time-Max:

  0.003 µs

• Surface Mount:

  YES

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10
