MAL212518222E3 - Vishay

Description: Aluminum Electrolytic Capacitors - Axial Leaded 2200UF 63V

Download MAL212518222E3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MAL212518222E3 - Vishay - PCB symbol
click to zoom
PCB Footprints
MAL212518222E3 - Vishay PCB footprint - Capacitors, Polarized Axial Diameter Horizontal Mounting - Capacitors, Polarized Axial Diameter Horizontal Mounting - 21X38
click to zoom
3D Models
MAL212518222E3 - Vishay - 3D model - Capacitors, Polarized Axial Diameter Horizontal Mounting - 21X38
click to zoom

MAL212518222E3 Details

  • Manufacturer Part Number:

    MAL212518222E3

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    AXIAL LEADED

  • Reach Compliance Code:

    Compliant

  • ECCN Code:

    EAR99

  • HTS Code:

    8532.22.00.40

  • Manufacturer:

    Vishay Intertechnologies

  • YTEOL:

    7.31

  • Capacitance:

    2200 µF

  • Capacitor Type:

    ALUMINUM ELECTROLYTIC CAPACITOR

  • Diameter:

    21 mm

  • Dielectric Material:

    ALUMINUM (WET)

  • ESR:

    72 mΩ

  • Leakage Current:

    0.297 mA

  • Length:

    38 mm

  • Mounting Feature:

    THROUGH HOLE MOUNT

  • Negative Tolerance:

    20%

  • Number of Terminals:

    2

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Style:

    Axial

  • Packing Method:

    Bulk

  • Polarity:

    POLARIZED

  • Positive Tolerance:

    20%

  • Rated (DC) Voltage (URdc):

    63 V

  • Reference Standard:

    AEC-Q200

  • Ripple Current:

    3780 mA

  • Surface Mount:

    NO

  • Tan Delta:

    0.12

  • Terminal Shape:

    WIRE

MAL212518222E3 Frequently Asked Questions (FAQs)

  • The recommended land pattern for MAL212518222E3 can be found in Vishay's application note AN10393, which provides guidelines for surface-mount assembly of Vishay's metal alloy resistors.
  • The power rating derating of MAL212518222E3 depends on the ambient temperature and the resistor's operating conditions. Vishay provides a derating curve in the datasheet, which should be consulted to determine the maximum power rating at a given temperature.
  • The MAL212518222E3 has a specified tolerance of ±1% at 25°C. Over time, the resistor's value may drift due to environmental factors, but Vishay guarantees that the resistor will remain within the specified tolerance over its operating life.
  • While the MAL212518222E3 is a general-purpose resistor, it is not optimized for high-frequency applications. For high-frequency use, Vishay recommends using their specialized high-frequency resistors, such as the HFC series.
  • To ensure the reliability of MAL212518222E3 in harsh environments, follow Vishay's recommended storage and handling procedures, and consider using conformal coating or potting to protect the resistor from moisture and contaminants.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MAL212518222E3 Overview

Use the download button to access the MAL212518222E3 schematic symbol, PCB footprint, and 3D model.
