MAOC-113100-TR0500 - MACOM

MAOC-113100-TR0500 Details

• Manufacturer Part Number:

  MAOC-113100-TR0500

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN-32

• Manufacturer:

  MACOM

• YTEOL:

  8.65

• Control Voltage-Max:

  12.5 V

• Control Voltage-Min:

  1.5 V

• Modulation Sensitivity:

  10 MHz/V

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  32

• Offset Frequency:

  10 kHz

• Operating Frequency-Max:

  13700 MHz

• Operating Frequency-Min:

  12500 MHz

• Operating Frequency-Nom:

  13100 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  VOLTAGE CONTROLLED OSCILLATOR

• Output Power:

  8 dBm

• Package Equivalence Code:

  LCC32,.2SQ,20

• Phase Noise:

  -81 dBc/Hz

• Physical Dimension:

  5.0mm X 5.0mm X 0.96mm

• Supply Current-Max:

  130 mA

• Supply Voltage-Max:

  5.25 V

• Supply Voltage-Min:

  4.75 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES
