Part Image

MAX14761ETB+T - Analog Devices

Description: Analog Switch ICs Above- and Below-the-Rails Low On-Resistance Analog Switches

Download MAX14761ETB+T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MAX14761ETB+T - Analog Devices PCB footprint - Small Outline No-lead - Small Outline No-lead - DFN_140
click to zoom
3D Models
MAX14761ETB+T - Analog Devices  - 3D model - Small Outline No-lead - DFN_140
click to zoom

MAX14761ETB+T Details

  • Manufacturer Part Number:

    MAX14761ETB+T

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    10-LFCSP-3X3X0.75

  • Package Description:

    TDFN-10

  • Pin Count:

    10

  • Manufacturer Package Code:

    10-LFCSP-3X3X0.75

  • Country Of Origin:

    Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2011-10-21

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Analog IC - Other Type:

    SPST

  • JESD-30 Code:

    S-PDSO-N10

  • JESD-609 Code:

    e3

  • Length:

    3 mm

  • Moisture Sensitivity Level:

    1

  • Normal Position:

    NO/NC

  • Number of Channels:

    1

  • Number of Functions:

    2

  • Number of Terminals:

    10

  • Off-state Isolation-Nom:

    77 dB

  • On-state Resistance Match-Nom:

    0.0051 Ω

  • On-state Resistance-Max (Ron):

    2 Ω

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    SEPARATE OUTPUT

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.8 mm

  • Signal Current-Max:

    0.25 A

  • Supply Current-Max (Isup):

    10 mA

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Switch-off Time-Max:

    1000000 ns

  • Switch-on Time-Max:

    300000 ns

  • Switching:

    BREAK-BEFORE-MAKE

  • Technology:

    BICMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3 mm

MAX14761ETB+T Frequently Asked Questions (FAQs)

  • A good PCB layout for the MAX14761ETB+T involves keeping the analog and digital grounds separate, using a solid ground plane, and placing the device close to the power supply. Additionally, it's recommended to use a 4-layer PCB with a dedicated layer for the analog signals, and to minimize the length of the traces connecting the device to the power supply and load.
  • To ensure proper power-up and initialization, make sure to follow the recommended power-up sequence, which involves applying the power supply voltage (VCC) before the input voltage (VIN). Also, ensure that the EN pin is pulled high to enable the device, and the FAULT pin is properly connected to a pull-up resistor and a capacitor to filter out noise.
  • Thermal management is crucial for the MAX14761ETB+T, as it can operate at high temperatures. Ensure good airflow around the device, and consider using a heat sink or thermal pad to dissipate heat. Also, keep the device away from other heat sources, and avoid using a PCB with a high thermal resistance.
  • To troubleshoot issues with the MAX14761ETB+T, start by checking the power supply voltage and input voltage levels. Verify that the EN pin is properly pulled high, and the FAULT pin is not asserting a fault condition. Use an oscilloscope to monitor the output voltage and current, and check for any signs of overheating or electrical noise.
  • Yes, the MAX14761ETB+T is a switching regulator, which can generate electromagnetic interference (EMI). To minimize EMI, use a shielded inductor, and ensure that the PCB layout is designed to minimize radiated emissions. Additionally, consider using EMI filters or shielding on the input and output lines.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MAX14761ETB+T Overview

Use the download button to access the MAX14761ETB+T schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MAX14, or try a keyword search, such as Multiplexers or Switches

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.

Parts related to MAX14761ETB+T

Showing 0 results
