MAX16141ADF/V+ - Analog Devices

Description: 3.5V to 36V Ideal Diode Controllers with Voltage and Current Circuit Breaker

Download MAX16141ADF/V+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MAX16141ADF/V+ - Analog Devices - PCB symbol
click to zoom
PCB Footprints
MAX16141ADF/V+ - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 16-LFCSP-4X4X0.75
click to zoom
3D Models
MAX16141ADF/V+ - Analog Devices - 3D model - Quad Flat No-Lead - 16-LFCSP-4X4X0.75
click to zoom

MAX16141ADF/V+ Details

  • Manufacturer Part Number:

    MAX16141ADF/V+

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    16-LFCSP-4X4X0.75

  • Package Description:

    TQFN-16

  • Pin Count:

    16

  • Manufacturer Package Code:

    16-LFCSP-4X4X0.75

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2018-08-18

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Additional Feature:

    LATCH OFF; THERMAL SHUTDOWN:145C

  • Adjustable Threshold:

    YES

  • Analog IC - Other Type:

    INPUT FAULT PROTECTION CONTROLLER

  • JESD-30 Code:

    S-XQCC-N16

  • JESD-609 Code:

    e3

  • Length:

    4 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC16,.16SQ,25

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    0.8 mm

  • Supply Current-Max (Isup):

    4 mA

  • Supply Voltage-Max (Vsup):

    36 V

  • Supply Voltage-Min (Vsup):

    3.5 V

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    QUAD

  • Threshold Voltage-Nom:

    +0.5V

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4 mm

MAX16141ADF/V+ Frequently Asked Questions (FAQs)

  • A good PCB layout for the MAX16141ADF/V+ involves keeping the input and output traces short and separate, using a solid ground plane, and placing the device close to the battery. Additionally, it's recommended to use a 4-layer PCB with a dedicated power plane and a dedicated ground plane to minimize noise and EMI.
  • The MAX16141ADF/V+ requires no calibration for voltage measurements, but current measurements require calibration using an external resistor (RSENSE) and a calibration procedure outlined in the datasheet. The calibration procedure involves measuring the voltage across RSENSE and adjusting the gain of the current sense amplifier to match the expected current range.
  • The MAX16141ADF/V+ has an operating temperature range of -40°C to +125°C, but the device's accuracy and reliability may be affected at extreme temperatures. It's recommended to operate the device within a temperature range of -20°C to +85°C for optimal performance.
  • Yes, the MAX16141ADF/V+ can be used with rechargeable batteries. To handle charging and discharging cycles, the device provides a CHG pin that can be used to detect charging and discharging events. The device also provides a VBAT pin that can be used to monitor the battery voltage and detect overcharge or over-discharge conditions.
  • The MAX16141ADF/V+ provides a 2-wire I2C interface for communication with microcontrollers or other digital systems. The device's registers can be accessed using the I2C interface, and the device provides interrupt outputs to notify the microcontroller of events such as overcharge or over-discharge conditions.
