MAX17311X+T - Analog Devices

Description: 1-Cell ModelGauge m5 EZ Fuel Gauge with Protector, Internal Self-Discharge Detection and SHA-256 Authentication

Download MAX17311X+T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MAX17311X+T - Analog Devices - PCB symbol
click to zoom
PCB Footprints
MAX17311X+T - Analog Devices PCB footprint - BGA - BGA - W151H2+1
click to zoom
3D Models
MAX17311X+T - Analog Devices - 3D model - BGA - W151H2+1
click to zoom

MAX17311X+T Details

  • Manufacturer Part Number:

    MAX17311X+T

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    15-WLCSP-N/A

  • Package Description:

    WLP-15

  • Pin Count:

    15

  • Manufacturer Package Code:

    15-WLCSP-N/A

  • Country Of Origin:

    Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2019-06-20

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Additional Feature:

    Cascade Function:N;CTL:Y;Integrated MOSFET:N;PS:N

  • Adjustable Threshold:

    YES

  • Analog IC - Other Type:

    BATTERY GAUGE

  • JESD-30 Code:

    R-PBGA-B15

  • Length:

    2.448 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    15

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    VFBGA

  • Package Equivalence Code:

    BGA15,3X5,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.69 mm

  • Supply Current-Max (Isup):

    0.05 mA

  • Supply Voltage-Max (Vsup):

    4.9 V

  • Supply Voltage-Min (Vsup):

    2.3 V

  • Supply Voltage-Nom (Vsup):

    3.6 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin/Silver/Copper/Nickel (Sn/Ag/Cu/Ni)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    BOTTOM

  • Threshold Voltage-Nom:

    +2.8V

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    1.678 mm

MAX17311X+T Frequently Asked Questions (FAQs)

  • The recommended layout and placement for the MAX17311X+T involves keeping the device close to the battery, using a solid ground plane, and minimizing the length of the high-current paths. It's also important to keep the device away from high-frequency noise sources and to use a low-ESR capacitor for the input and output filters.
  • The selection of external components for the MAX17311X+T depends on the specific application requirements. For example, the input and output capacitors should be chosen based on the desired ripple voltage and ESR. The inductor value should be selected based on the desired output voltage and current. The datasheet provides guidelines for selecting these components, but simulation tools and application notes can also be helpful.
  • The maximum ambient temperature range for the MAX17311X+T is -40°C to +125°C. However, the device's performance and reliability may be affected at extreme temperatures, so it's important to consider the specific application requirements and to consult the datasheet and application notes for more information.
  • To troubleshoot common issues with the MAX17311X+T, start by checking the input voltage, output voltage, and current levels to ensure they are within the specified ranges. Check the device's thermal performance and ensure that the PCB layout and thermal design are adequate. Consult the datasheet and application notes for troubleshooting guidelines and use oscilloscopes and other diagnostic tools to identify the root cause of the issue.
  • The MAX17311X+T is a high-reliability device, but it's essential to consult the datasheet and application notes to ensure that it meets the specific requirements of the application. Additionally, Analog Devices provides a range of resources, including failure-in-time (FIT) rates and mean time between failures (MTBF) data, to help engineers evaluate the device's suitability for high-reliability or safety-critical applications.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MAX17311X+T Overview

Use the download button to access the MAX17311X+T schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MAX17, or try a keyword search, such as Power Management Circuits

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
