MAX20412ATJD/V+T Details

  • Manufacturer Part Number:

    MAX20412ATJD/V+T

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    32-LFCSP-5X5X0.75

  • Package Description:

    TQFN-32

  • Pin Count:

    32

  • Manufacturer Package Code:

    32-LFCSP-5X5X0.75

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2019-10-25

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Additional Feature:

    IT ALSO HAS PFM CONTROL TECHNIQUE

  • Analog IC - Other Type:

    DUAL SWITCHING CONTROLLER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    5.5 V

  • Input Voltage-Min:

    3 V

  • Input Voltage-Nom:

    5 V

  • JESD-30 Code:

    S-XQCC-N32

  • JESD-609 Code:

    e3

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    32

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    60 A

  • Output Voltage-Max:

    1.275 V

  • Output Voltage-Min:

    0.25 V

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC32,.2SQ,20

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    0.8 mm

  • Surface Mount:

    YES

  • Switcher Configuration:

    BUCK

  • Switching Frequency-Max:

    2400 kHz

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    5 mm

MAX20412ATJD/V+T Frequently Asked Questions (FAQs)

  • A good PCB layout for the MAX20412 involves keeping the analog and digital grounds separate, using a solid ground plane, and placing the device close to the power supply. Additionally, it's recommended to use a 4-layer PCB with a dedicated layer for the analog signals, and to minimize the length of the traces connecting the device to the power supply and load.
  • To ensure proper power-up and configuration, follow the recommended power-up sequence, which is to apply the power supply voltage (VCC) before the input voltage (VIN). Also, make sure to configure the device's registers according to the datasheet, and use the correct clock frequency and mode for your application.
  • The MAX20412 has a maximum junction temperature of 150°C. To prevent overheating, ensure good airflow around the device, use a heat sink if necessary, and avoid operating the device at maximum power dissipation for extended periods. Also, monitor the device's temperature using the thermal monitoring feature and take corrective action if necessary.
  • To troubleshoot issues with the MAX20412, start by reviewing the datasheet and application notes to ensure correct usage and configuration. Use a logic analyzer or oscilloscope to monitor the device's signals and identify any anomalies. Check for proper power supply and clock signals, and verify that the device is properly configured and initialized. If necessary, contact Analog Devices' technical support for further assistance.
  • Yes, the MAX20412 is a high-frequency device and requires proper EMI/EMC design considerations. Use a shielded enclosure, keep the device away from other noise-sensitive components, and use EMI filters or shielding on the input and output lines. Also, follow good PCB design practices, such as using a solid ground plane and minimizing trace lengths.
