MAX31329ELB+ - Analog Devices

Description: Real Time Clock Integrated RC17 w/ QST Crystal

Download MAX31329ELB+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MAX31329ELB+ - Analog Devices PCB footprint - Other - Other - L1055M+2C
click to zoom
3D Models
MAX31329ELB+ - Analog Devices  - 3D model - Other - L1055M+2C
click to zoom

MAX31329ELB+ Details

  • Manufacturer Part Number:

    MAX31329ELB+

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    10-LGA-5X5X1.25

  • Pin Count:

    10

  • Manufacturer Package Code:

    10-LGA-5X5X1.25

  • Country Of Origin:

    Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2021-09-03

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Moisture Sensitivity Level:

    3

MAX31329ELB+ Frequently Asked Questions (FAQs)

  • A good PCB layout for the MAX31329ELB+ involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing noise coupling between the crystal oscillator and the digital circuits. A 4-layer PCB with a dedicated ground plane is recommended. Additionally, the device's exposed pad should be connected to a solid ground plane to improve thermal performance.
  • To ensure the accuracy of the RTC, it is essential to use a high-quality crystal oscillator with a frequency tolerance of ±20 ppm or better. The crystal oscillator should also be driven by a suitable load capacitance, and the RTC clock output should be decoupled from the digital circuits to minimize noise coupling. Additionally, the device's internal oscillator can be calibrated using the CAL register to improve accuracy.
  • The MAX31329ELB+ is specified to operate over a temperature range of -40°C to +125°C. However, the device's accuracy and reliability may be affected at extreme temperatures. It is recommended to operate the device within a temperature range of -20°C to +85°C for optimal performance.
  • The MAX31329ELB+ can be interfaced with a microcontroller using a standard I²C or SPI interface. The device's address pins (A0, A1, and A2) should be connected to the microcontroller's address lines, and the SCL/CLK and SDA/MOSI pins should be connected to the microcontroller's clock and data lines, respectively. The microcontroller should also provide a suitable power supply and clock signal to the MAX31329ELB+.
  • The power consumption of the MAX31329ELB+ depends on the operating mode and frequency. In the active mode, the device consumes around 1.2 mA at 3.3 V and 32 kHz. In the standby mode, the device consumes around 0.5 μA at 3.3 V. The power consumption can be further reduced by using the device's power-down mode.
