MAX32674CGWG+T - Analog Devices

Description: SENSOR/ALGORITHM HUB

Download MAX32674CGWG+T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MAX32674CGWG+T - Analog Devices PCB footprint - BGA - BGA - MAX32674CGWG+T   24PIN
click to zoom
3D Models
MAX32674CGWG+T - Analog Devices  - 3D model - BGA - MAX32674CGWG+T   24PIN
click to zoom

MAX32674CGWG+T Details

  • Manufacturer Part Number:

    MAX32674CGWG+T

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Part Package Code:

    24-WLCSP-N/A

  • Pin Count:

    24

  • Manufacturer Package Code:

    24-WLCSP-N/A

  • Date Of Intro:

    2022-06-17

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    3

  • Sensors/Transducers Type:

    SENSOR/TRANSDUCER CIRCUIT

  • Terminal Finish:

    Tin/Silver/Copper/Nickel (Sn/Ag/Cu/Ni)

MAX32674CGWG+T Frequently Asked Questions (FAQs)

  • The recommended crystal oscillator frequency for the MAX32674CGWG+T is 32.768 kHz, which is the typical frequency used for real-time clock (RTC) applications.
  • To configure the MAX32674CGWG+T for low-power mode, you need to set the Power Mode Control Register (PMC) to enable the low-power mode, and then configure the clock control registers to reduce the clock frequency and disable unnecessary peripherals. Additionally, you can use the Power Management Interface (PMI) to control the power modes of individual peripherals.
  • The maximum current consumption of the MAX32674CGWG+T depends on the operating mode and the peripherals used. According to the datasheet, the maximum current consumption is around 150 mA in active mode, and around 10 μA in shutdown mode.
  • Yes, the MAX32674CGWG+T has an external memory interface that allows you to connect external memory devices such as flash memory or SRAM. You need to configure the External Memory Interface (EMI) registers to enable the external memory interface and set the memory timing parameters.
  • To implement secure boot on the MAX32674CGWG+T, you need to use the Secure Boot Loader (SBL) feature, which is a built-in feature of the microcontroller. You need to generate a secure boot image using the Analog Devices Inc. Secure Boot Tool, and then program the image into the microcontroller's flash memory.
