MAX8215CSD+ - Analog Devices

Description: MAX8215CSD+, Voltage Supervisor 5-channel

Download MAX8215CSD+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MAX8215CSD+ - Analog Devices - PCB symbol
click to zoom
PCB Footprints
MAX8215CSD+ - Analog Devices PCB footprint - Small Outline Packages - Small Outline Packages - MAX 14 SO
click to zoom
3D Models
MAX8215CSD+ - Analog Devices - 3D model - Small Outline Packages - MAX 14 SO
click to zoom

MAX8215CSD+ Details

  • Manufacturer Part Number:

    MAX8215CSD+

  • Brand Name:

    Analog Devices Inc

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    14-SOIC_N-150_MIL

  • Package Description:

    LEAD FREE, PLASTIC, SOP-14

  • Pin Count:

    14

  • Manufacturer Package Code:

    14-SOIC_N-150_MIL

  • Country Of Origin:

    Japan, Mainland China, Malaysia, Philippines, Singapore, South Korea, Taiwan, Thailand, USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    1993-08-01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    VOLTAGE SUPERVISOR/RESET IC

  • JESD-30 Code:

    R-PDSO-G14

  • JESD-609 Code:

    e3

  • Length:

    8.65 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    5

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.75 mm

  • Supply Current-Max (Isup):

    0.25 mA

  • Supply Voltage-Max (Vsup):

    11 V

  • Supply Voltage-Min (Vsup):

    2.7 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3.9 mm

MAX8215CSD+ Frequently Asked Questions (FAQs)

  • The MAX8215CSD+ is a high-frequency device, and proper layout and placement are crucial for optimal performance. It is recommended to follow the layout guidelines provided in the datasheet, including keeping the input and output traces short and away from noise sources, and using a solid ground plane to reduce noise and radiation.
  • The MAX8215CSD+ requires a specific bias voltage and current to operate optimally. Ensure that the VCC pin is connected to a stable voltage source between 2.7V and 5.5V, and that the ISET pin is connected to a resistor that sets the desired output current. Refer to the datasheet for specific biasing requirements and recommendations.
  • The MAX8215CSD+ is rated for operation over the extended industrial temperature range of -40°C to +125°C. However, the device's performance and accuracy may degrade at extreme temperatures. Ensure that the device is operated within the recommended temperature range for optimal performance.
  • The MAX8215CSD+ is a sensitive device and can be damaged by electrostatic discharge. Ensure that all handling and assembly procedures follow proper ESD precautions, including the use of ESD-safe materials, wrist straps, and workstations. Additionally, consider adding ESD protection devices, such as TVS diodes, to the circuit design.
  • The MAX8215CSD+ is a high-reliability device, but it is not specifically designed for safety-critical applications. However, it can be used in high-reliability applications with proper design, testing, and validation. Ensure that the device is operated within its recommended specifications and that the system design includes adequate fault detection and mitigation mechanisms.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MAX8215CSD+ Overview

Use the download button to access the MAX8215CSD+ schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MAX82, or try a keyword search, such as Power Management Circuits

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
