MAX8895VEWA+ - Analog Devices

MAX8895VEWA+ Details

• Manufacturer Part Number:

  MAX8895VEWA+

• Brand Name:

  Analog Devices Inc

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  25-WLCSP-N/A

• Package Description:

  WLP-25

• Pin Count:

  25

• Manufacturer Package Code:

  25-WLCSP-N/A

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2010-08-24

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  10

• Additional Feature:

  THERMAL SHUTDOWN:160C

• Adjustable Threshold:

  YES

• Analog IC - Other Type:

  LINEAR BATTERY CHARGER

• JESD-30 Code:

  R-XBGA-B25

• Length:

  2.305 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  WFBGA

• Package Equivalence Code:

  BGA25,5X5,16

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY VERY THIN PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  0.69 mm

• Supply Current-Max (Isup):

  500 mA

• Supply Voltage-Max (Vsup):

  6.6 V

• Supply Voltage-Min (Vsup):

  4 V

• Surface Mount:

  YES

• Technology:

  BICMOS

• Terminal Finish:

  Tin/Silver/Copper/Nickel (Sn/Ag/Cu/Ni)

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Threshold Voltage-Nom:

  +4.2V

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  2.305 mm
